SunnySky X2216 V3 Brushless Motors Short Shaft Version 1250KV
by SunnySky

Introducing the SunnySky X Series V3 X2216 Brushless Motor 1250KV Short Shaft—a high-performance motor engineered for RC enthusiasts seeking exceptional power and efficiency. Designed with precision and durability in mind, this motor is ideal for aerobatic and 3D model aircraft.

Product Description: The SunnySky X2216 V3 1250KV Brushless Motor features a robust construction with a stator diameter of 22mm and a thickness of 16mm, ensuring optimal performance for various RC applications. Its 14-pole design and high-quality components, including Japanese NMB bearings and a CNC-machined aluminum case, provide smooth operation and longevity. Weighing approximately 69 grams, this motor delivers a maximum continuous power of 600W, making it suitable for aerobatic models up to 850 grams and 3D models up to 750 grams. The short shaft design simplifies installation, eliminating the need for fuselage modifications.

Specifications:

• Stator Dimensions: 22mm (Diameter) x 16mm (Thickness)
• KV Rating: 1250KV
• Number of Stator Slots: 12
• Number of Rotor Poles: 14
• No-Load Current: 1A at 10V
• Motor Resistance: 45mΩ
• Maximum Continuous Current: 40A for 30 seconds
• Maximum Continuous Power: 600W
• Weight: 69g
• Rotor Diameter: 27.7mm
• Body Length: 34mm
• Recommended Battery: 3S-4S LiPo
• Recommended ESC: 40A-50A
• Recommended Propellers: 9 to 11 inches

Included in the Package:

• 1 x SunnySky X2216 V3 1250KV Brushless Motor (Short Shaft)
• 1 x Propeller Collet Adapter with Screws
• 1 x X-Mount Bracket with Screws
