ImpulseRC Helix ZX5 FPV Frame
by Impulse RC
$209.99 $61.74
Notify me when this is in stockDiscontinued
- Brand: Impulse RC
- Model: 4058642477
- RMRC Win: 84224
- Shipping Weight: 0.56
- Country of Origin: CN
- Copy Referral Link
This product requires an amateur radio license to operate legally in the US. Please read the Amateur Radio Info before purchasing
HELIX ZX5 FPV RACING FRAME
Simply put, the Helix ZX5 deserves an award for innovation in racing frame design. With a square motor layout and a custom designed ultra-compact core, it set new standards for FPV racing frames. In the hands of Australian pilot Thomas "BMSThomas" Bitmatta, the Helix has won both National and International races!
The frame structure is made from durable high quality carbon with chamfered edges. It uses aluminum hardware for most mounting points except the core which uses high tensile steel screws. A lot of thought has been put into the core of the frame - everything fits together nicely with minimal wasted space. The standard-size FPV camera is fully protected by the carbon side plates, the ESC’s are protected by injection molded plastic fairings and the rest of the electronics are out of harm’s way. The FPV antenna has been designed to take strain away from the SMA connector, and the receiver antennas are protected by stiff tubes that keep them out of the prop disc.
CUSTOM FLIGHT CONTROLLER One thing that sets the Helix apart from the competition is that it has a custom designed FC and VTx. The flight controller runs BetaFlight on a STM32 F3 chip, with a low noise MPU6000 Gyro. It is packed with features, among which are 6S capability, built in microphone, built in PDB, LED outputs, ultra-clean filtered outputs for FPV, Integrated OSD and more!
CUSTOM VIDEO TRANSMITTER The 40 channel video transmitter serves as a structural part of the Helix, holding the camera side plates in place. It’s built on a very thick circuit board to insure durability, and can provide a selectable output of 25, 200 and 500 mW of clean video transmission. Power and frequency are easily changeable through the OSD.
These are the component recommendations for this frame:
- FPV camera - HS1177 (top connector) (Rotor Riot Swift 2 fits with slight reaming of side plates)
- RC receiver - No larger than FrSky X4R-SB
- FPV antenna - Axii - SMA
- Motors - 2204-2207 class motors to suit prop size (19x19 motor base)
- ESCs - Aikon 30A or 30A+ ESC's smaller than 30mm x 15mm x 4.5mm
| Name | Value |
|---|---|
| MANUFACTURER | Impulse RC |
Related Products
US Customers:
This equipment is being sold under the FCC’s amateur radio rules. Operators must abide by all applicable laws and hold an amateur license to operate this equipment. Use of amateur equipment without a license or use of equipment on restricted frequencies could subject the operator to significant fines by the FCC. By purchasing this equipment, the user is agreeing that they understand these responsibilities and will operate the equipment legally. For information regarding obtaining an amateur radio license, please go to http://www.arrl.org/getting-licensed.
47 CFR 97.215(c) sets a 1 watt limit for amateur devices being used for telecommand. Devices over 1 watt output should not be used for telecommand of model aircraft.
International Customers:
The use and operation of this product in your country may require an amateur radio license, and some countries may forbid its use entirely. It is the responsibility of the purchaser to ensure that the purchase and use of this product meets the requirements imposed by your government’s rules and regulations for RF devices. Do not purchase this product if you are unsure of the government requirements or are not able to comply with them. Ready Made RC, LLC cannot be held responsible for your actions if you purchase and/or use this product in violation of your government's regulations.
