SunnySky X Series V3 X2814 Brushless Motor 1200KV
by SunnySky

The SunnySky X2814 V3 1200KV Brushless Motor is engineered for RC airplanes, multi-rotors, and UAV applications, delivering exceptional efficiency, power, and durability. Designed with precision CNC-machined components, this lightweight yet powerful motor ensures smooth and stable flight performance.

The X Series V3 motors are known for their high power-to-weight ratio, low operating temperature, and optimized efficiency, making them an excellent choice for both fixed-wing planes and multi-rotor drones. Its precision-balanced rotor minimizes vibration, improving motor lifespan and enhancing flight stability.

Features:

• High-performance 1200KV outrunner brushless motor
• Precision CNC-machined aluminum casing for durability
• Optimized stator design for efficiency and power output
• High-quality bearings for smooth, reliable operation
• Low operating temperature for extended motor lifespan
• Pre-soldered motor leads for easy installation
• Compatible with a wide range of fixed-wing aircraft, UAVs, and multi-rotors

Specifications:

• Motor KV: 1200KV
• Stator Diameter: 28mm
• Stator Length: 14mm
• Motor Shaft Diameter: 4mm
• Motor Dimensions: Ø35 x 34mm
• Weight: 106g
• Operating Voltage: 3S-4S LiPo
• Recommended Propellers: 9-11 inch (on 3S-4S)
• Max Continuous Current: 45A
• Max Power Output: 700W
