Introducing the Mr. Steele V5 Stout 2307 (1950KV) 6S (5”-5.5” prop) FPV freestyle motor. The Stout motor is wound at 1950KV for extra power and speed.
The V5 features an increased stator size and a redesigned motor bell setup for more durability. This new iteration of my trusted power train formula follows a lightweight ethos with increased power and torque where it counts. Attaining a high power-to-weight ratio cannot overstate when building a high-performance aircraft. The V5 Silk add confidence with even heavier HD cameras.
Thank you for your support and take pride in knowing that you are the reason I am able to keep evolving in this amazing space we call the FPV community.
All in all this motor is an absolute gem only increasing the weight by a tad over 1g from the previous model while achieving more power, efficiency, and most importantly durability.
Enjoy & Thank you for your continued support. -Steele
Stator Size (Diameter) | 23mm*7mm |
Kv | 1950kv |
Magnets | N52SH Curved |
Windings | 13turn DLRK |
Shaft Length (mm) | 10.5mm |
Shaft Diameter (mm) | 4mm |
Shaft material | Steel |
Bearing | NMB684 |
Weight (With Wires)(g) | 36.5g |
Cells (Lipo) | 6S |
Max Current (A) | 45A |
Max Burst Current (A) | 60A |
Internal Resistance (Rm) | 60mΩ |
Wire Spec (AWG) | 20#-135mm |
Base Mounting Pattern | 16x16mm |
Base Mounting Thread | M3 Thread |
Motor Overall Dimensions | φ28.6mm*18.2mm |
Name | Value |
---|---|
MANUFACTURER | Ethix |
STATOR DIAMETER | 23 |
STATOR HEIGHT | 7 |
KV | 1950 |
THREAD DIRECTION | Standard |
SHAFT FOR COLLET MOUNT | no |
