Mauch MH021: PL 4-14S HYB-BEC / 1x5.3V
by Mauch

Mauch MH021: PL 4-14S HYB-BEC / 1x5.3V

Specs

• Premium-Line 4-14s BEC with 1 x 5.35V output.
• Input 4-14S LiPo / max. 60V.
• Output 5.30V / 3A -> +/- 0.05V –> Ripple 1mV @ 1.5A output current.
• Inclusive LDO power supply (+5.00V +/- 0.03V) for the sensor board PL-xxx as well as PL- Sensor Hub X2/X8 and output connector with Molex Clik-Mate 4p.
• Blue power "ON' LED.
• 59mm x 29mm x 13mm / 26g with enclosure(without cables)
• Delivery in PP box: 55 x 55 x 20mm
